Chevrolet Captiva Service & Repair Manual: HVAC Blower Motor R&R

Chevrolet Captiva Service & Repair Manual / Air Conditioning & Heater / HVAC Blower Motor R&R

1.	Disconnect electrical connector from blower motor.

2.	Remove blower motor bolts from HVAC module, Fig. 1.

3.	Remove blower motor from HVAC module, Fig. 1.

4.	Reverse procedure to install.

Fig. 1
