Chevrolet Captiva Service & Repair Manual: Front Bumper

Removal

1. Remove front compartment front sight shield.
2. Remove front screws from front wheelhouse liner.
3. Remove three front bumper lower bolts, Fig. 1.
4. Remove two front bumper screws, Fig. 1.
5. Carefully push a small nylon wedge between fascia and fender. Insert a small flat-bladed tool into fascia slot and depress tabs one at a time and pull on fascia at same time to gradually remove fascia from fender.
6. Disconnect electrical connectors.
7. Remove front bumper.

Installation

1. Reverse procedure to install.
2. Torque bolts to 53 inch lbs.
3. Torque screws to 53 inch lbs.

Fig. 1 Front bumper removal
