Chevrolet Captiva Service & Repair Manual: Grille

Removal

1. Remove front bumper as outlined in Front Bumper.
2. Remove radiator grille emblem.
3. Remove six grille screws, Fig. 1.
4. Release tabs from radiator upper grille assembly and remove.

Installation

Reverse procedure to install.

Fig. 1 Grille removal
