Chevrolet Captiva Manuals

Chevrolet Captiva Service & Repair Manual: Window Regulator Motor R&R

Front

1. Remove front side door window regulator, Fig. 1.
2. Remove front side door window regulator motor screws, Fig. 1.
3. Remove front side door window regulator motor, Fig. 1.
4. Reverse procedure to install. Torque regulator motor bolts to 71 inch lbs.

Rear

1. Remove rear side door window regulator.
2. Remove rear side door window regulator motor screws, Fig. 2.
3. Remove rear side door window regulator motor, Fig. 2.
4. Reverse procedure to install. Torque regulator motor bolts to 71 inch lbs.

Fig. 1

Fig. 2
