Chevrolet Captiva Service & Repair Manual: Hood Support Strut R&R

Warning: When a hood hold open device is being removed or installed, provide alternate support to avoid possibility of damage to vehicle or personal injury.
1. Release locking tabs on strut, Fig. 1.
2. Ensure clip is fully seared when rod is reinstalled. If clip cannot be fully seated a new rod should be installed, Fig. 1.
3. Remove hood strut, Fig. 1.
4. Reverse procedure to install.

Fig. 1
